elterra.co.id
Elterra
Electric Water Heater
HE30-GC (30 Liter)
HE50-GC (50 Liter)
HE80-GC (80 Liter)
HE100-GC (100 Liter)
Dengan Keunggulan Kami, Membuat Mandi Anda Jauh Lebih Nyaman, Aman dan Berkualitas.
WHAT’S INSIDE
- High Quality Heating Element
Offers superior heating performance with extended life span and minimum energy losses. ( Available with glasslined / incoloy / copper selections )
- Heavy Gauge Tank
Made by ultra thick super cold-rolled steel plate with 1.8 – 2 mm thickness.
- Blue Diamond Enamel Coating Layer
All models are equipped with ultimate protection against rust and corrosion. Blue Diamond layer (0.5mm) provides several times the corrosion resistance compared to standard inner tank designs.
- Heavy-Duty/G-Tech Anode Rod
With steel core, protects Blue Diamond tank from rust and corrosion.
- Energy Saving High Density
Foam Insulation CFC free, complete protection design against radiant heat loss (Up to 25% thicker than normal insulation design).
- Water Tubes With Whirlflow 2/3
Ensures no immediate direct contact between cold & hot water for a faster heating and maximum energy saving effect. A further improvement based on classic whirlflow design with up to 20% more hot water output.
- Multifunctional Safety Valve
Automatically relieves and discharges water in case the temperature or pressure overshoots the preset limits. Also targets a quick startup under extreme pressure conditions from pressure of 0.005 MPa to 0.8MPa.
- Service Panel
Anti-scratch and immersed lock design, provides convenient way for part replacement.
- Adjustable Temperature
“One-Hand” pilot design, allows a temperature setting between 25°Cto75°C.
- 5-Bolt Flange
Provides an easier way for product maintenance.
- Knob
- Temperature Meter
Improved Energy Saving
Polyurethane / Cyclopentane Foam
CFC free, complete protection design against radiant heat loss. (Up to 25% thicker than normal insulation design)
S.L.O.T
Crust structure optimized with SLOT (Standing Loss Optimization Technology), contributes to less standing loss performance while keeping product in original sleek design.
More Hot Water
Whirlflow Technology
With patented whirlflow 3 design, cold water is marshalled at the bottom while hot water flow Is being pushed up to upper space.
It avoids immediate direct contact between cold & hot water flow for a faster heating and optimized energy saving effect.
Whirlflow2 is with 15% more hot water output;
Whirlflow3 is with 20% more hot water output.
Overheat Protection
Dry Heating Prevention
Stops heating process to prevent dry heating and further protects the life of heating element when there’s little water left and product is overheated.
Double Wires Cutout
Disconnects both Null & Fire wire connections for a complete safety of product usage when water temperature overshoots.
G-Tech Resistor Magnesium
With Extra Embedded Resistance
The G-tech resistor magnesium is our brand-new feature with extra embedded resistor. It provides an over Ave times longer life in compare to regular one with a thorough protection to inner tank from rust and corrosion. Highly recommend for markets with water quality under extreme conditions.
ELCB
Device For Extra Safety And Life-long Durability
The ELCB (Earth Leakage Circuit Breaker) is designed to prevent shock and injury to users.
lt qulckly disconnects a circuit whenever detecting animbalance of electric current, which is sometimescaused by current leakage through the body of people who is grounded and accidentally touching the electriferous part of the circuit.
With Exclusive Single Weld Line Design
Provides several times the corrosion resistance and anti-rust effects compared to standard inner tank designs.
Single weld line on the inner tank, reduces over 67% of water leakage risk.
A Die-Hard life span. Pass through multiple testings including: Acidurictest: 15% vitriol/ 48 hours; Anti-alkaline test 20% brine/ 15 days; Fatigue test: 0.2-0.8MPa, repeat 300,000Times (UL Standard: 100,000 times); Environment synchronization test.
Smart Digital System
Design For Intelligent Life
STD/Timer/ECO/Anti Bacteria modes Smart system designed for hot water supply anytime, touch button brings fantastic appearance and enjoyable operation, and programmed model can follow your habit to provide hot water timely.
All the smart ideals are designed for your intelligent and ECO life,and antibacteria function will be a safeguard for your family.
Top Quality Heating Elements
Glasslined Heating Element
Scale and sediment build up on the surface of standard elements leads to electricity waste and premature failure. Our imported enameled element helps to prevent sediment formation and extend the life span of the products.
Incoloy800, lncoloy840 Heating Element
The imported lncoloy heating element is highly sought after due to its excellent ability to resist both oxidization and carbonization in high-temperature settings. What’s more it staves off erosion in a number of aqueous atmospheres including the most extreme water conditions. These features have made lncoloy element an industrial recognition and the image of superior quality.
Copper Heating Element
Compared to regular stainless steel heating element ,it offers a stronger resistance to both acid and alkaline substance, also it has better longevity and a better proof to rust and scale formation.
Dry Heating Element With Enameled Flange
Special blue coating enamel Hange prevents limescale adhering and limestone formation. Long life span of heating element due to absence of limescale and no direct contact with water
High Hydraulic Pressure Protection
Over Pressure Prevention
Self releases inner tank pressure when it exceeds 0.8 MPa and further prevents water backflow in case of no water supply to ensure the safety of performance.
T&P Valve
Double protection for high pressure (0.8MPa or 1.03MPa) and temperature (99°C)
Features
Incoloy 804 Heating Element
ELCB
Energy Saving
Thermal Stabiliy Device
Easy Maintenance
Hot Water Ready Indicator
Total Safety System
Bath Deco
Splash-Proof Protection
Compact Design
Product Variant
| Elterra HE30-GC | |
|---|---|
Capacity | 30 L |
Voltage | 220 V |
Power | 500 / 1000 / 1500 (V) |
Adjustable Water Temp | Ambient to 750C |
Rate Pressure | 0.8 Mpa |
Dimension (H/D) | 650 / 340 (mm) |
Weight | 13.2 Kg |
Water Proof Degree | IPx4 |
Packing Size | 435 x 395 x 760 mm |
| Elterra HE50-GC | |
|---|---|
Capacity | 50 L |
Voltage | 220 V |
Power | 500 / 1000 / 1500 (V) |
Adjustable Water Temp | Ambient to 750C |
Rate Pressure | 0.8 Mpa |
Dimension (H/D) | 910 / 340 (mm) |
Weight | 17.4 Kg |
Water Proof Degree | IPx4 |
Packing Size | 435 x 395 x 1010 mm |
| Elterra HE80-GC | |
|---|---|
Capacity | 80 L |
Voltage | 220 V |
Power | 500 / 1000 / 1500 (V) |
Adjustable Water Temp | Ambient to 750C |
Rate Pressure | 0.8 Mpa |
Dimension (H/D) | 918 / 410 (mm) |
Weight | 22 Kg |
Water Proof Degree | IPx4 |
Packing Size | 495 x 365 x 1040 mm |
| Elterra HE100-GC | |
|---|---|
Capacity | 100 L |
Voltage | 220 V |
Power | 500 / 1000 / 1500 (V) |
Adjustable Water Temp | Ambient to 750C |
Rate Pressure | 0.8 Mpa |
Dimension (H/D) | 1095 / 410 (mm) |
Weight | 25.7 Kg |
Water Proof Degree | IPx4 |
Packing Size | 495 x 365 x 1220 mm |
